Zotac ZBOX CI649 NANO 1.8L sized PC Black, White i5-1335U Intel SoC 1.3 GHz
- Powwerful Silence
- The Ideal Office Assistant
MULTI-TASK. EMAIL. DOCS. FASTER
The all-new compact ZBOX C Series nano is a leader in silent computing performance. Its rigid enclosure is patterned with nature’s strongest natural structure, further enhanced by 270 degrees of open ventilation for maximum breathability and operability.
DEDICATED
The all-new ZBOX C Series nano Mini PC is an efficiently fast multi-core, multi-threaded multitasker that’s dedicated to help get work done.
EFFICIENT AND RELIABLE
A system that takes up very little space and it’s designed with no moving parts* to remove wear and tear inefficiencies to increase overall system reliability, longevity, and return on investment. At 1.8 liters small, its energy consumption is just as small and efficient, sipping up to 30W under load for additional long term cost savings
Flexible
The ZBOX C Series nano features a built-in VESA mount design to allow for more flexible system placement. The overall small system takes very little desk space, but it also has the potential to take up zero if mounted onto a wall, under the desk, or even behind the display.
HAS GREAT COMMUNICATION
The ZBOX C Series nano’s compact footprint packs in a plethora of built-in fast connectivity which include: WiFi 6, Bluetooth 5.2, Gigabit LAN, and 2.5Gbps LAN. It can also provide great visibility with the ability to support up to 3 displays with HDMI 2.0b, DisplayPort 1.4, and DP via Thunderbolt. The available Thunderbolt 4, USB 3.1, and SDXC Card Reader allows for easy file transfers between devices.
CAN TAKE ON MORE
The ZBOX C Series nano can take on up to 64GB of fast DDR5 5200/4800 MHz Memory, a 2.5” HDD/SSD drive, and an M.2 NVMe PCIe 4.0 x4 SSD with little effort.
| Processor | |
|---|---|
| Thermal Design Power (TDP) | 55 W |
| Processor cache | 12 MB |
| Efficient-core boost frequency | 3.4 GHz |
| Performance-core boost frequency | 4.6 GHz |
| Efficient cores | 8 |
| Performance cores | 2 |
| Processor frequency | 1.3 GHz |
| Processor threads | 12 |
| Processor cores | 10 |
| Processor model | i5-1335U |
| Processor generation | 13th gen Intel® Core™ i5 |
| Processor family | Intel® Core™ i5 |
| Processor manufacturer | Intel |
| Built-in processor | Yes |
| Memory | |
|---|---|
| Maximum internal memory | 64 GB |
| Memory channels | Dual-channel |
| Supported memory types | DDR5-SDRAM |
| Supported memory clock speeds | 4800,5200 MHz |
| Number of memory slots | 2 |
| Memory slots type | SO-DIMM |
| Storage | |
|---|---|
| Compatible memory cards | SD, SDHC, SDXC |
| Card reader integrated | Yes |
| Number of storage drives supported | 2 |
| Storage drive interface | PCI Express, Serial ATA |
| Storage drive sizes supported | 2.5,M.2 |
| Supported storage drive types | HDD & SSD |
| Graphics | |
|---|---|
| Number of displays supported | 3 |
| Maximum resolution | 4096 x 2160 pixels |
| On-board graphics card model | Intel Iris Xe Graphics |
| Graphics card family | Intel |
| On-board graphics card | Yes |
| Audio | |
|---|---|
| Built-in speaker(s) | No |
| Network | |
|---|---|
| Bluetooth | Yes |
| Bluetooth version | 5.2 |
| Wi-Fi standards | Wi-Fi 6 (802.11ax) |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi | Yes |
| Ethernet LAN | Yes |
| Ports & interfaces | |
|---|---|
| Thunderbolt 4 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Headphone outputs | 1 |
| Microphone in | Yes |
| DisplayPort version | 1.4 |
| DisplayPorts quantity | 1 |
| HDMI version | 2.0b |
| HDMI ports quantity | 10 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 2.0 ports quantity | 1 |
| Design | |
|---|---|
| Product type | Workstation barebone |
| VESA mounting | Yes |
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| LED indicators | HDD, Power, Wi-Fi |
| On/off switch | Yes |
| Cooling type | Passive |
| Product colour | Black, White |
| Chassis type | 1.8L sized PC |
| Performance | |
|---|---|
| Audio output channels | 8.0 channels |
| Motherboard chipset | Intel SoC |
| General | |
|---|---|
| Product family | ZBOX |
| Software | |
|---|---|
| Windows operating systems supported | Windows 11 |
| Power | |
|---|---|
| Number of power supply units | 1 |
| Power supply | 65 W |
| Power supply type | External AC adapter |
| Weight & dimensions | |
|---|---|
| Height | 68 mm |
| Depth | 129 mm |
| Width | 204 mm |
| Packaging content | |
|---|---|
| Quick start guide | Yes |
| AC adapter included | Yes |
| Power cord included | Yes |
