Vertiv Liebert Power output distribution (POD) with (4) IEC320-32A & (4) IEC320-C13 output sockets compatible with APS
- Power output distribution unit with UPS maintenance bypass feature
- Avoid initiating unnecessary downtimes while conducting UPS maintenance
- Easy plug-and-play deployment to ensure continuous uptime of your network even during UPS maintenance
- Output: Four (4) IEC320-C19 , Four (4) IEC320-C13 / Max Current: 63A
- Input: Hardware 3W + G(L-L-N-G)
The Vertiv Liebert POD PD2-200 is a power output distribution (POD) unit with built-in maintenance bypass feature. Designed for the GXT4 8-10kVA & GXT5 16-20kVA uninterruptible power supply (UPS) models, it is a POD that allows you to conduct UPS maintenance or replacements without power interruption to the connected load. It also automatically transfers the current from the UPS to the original power source in cases of UPS failures, saving your equipment from unnecessary downtimes and ensuring continuous uptime for your system. The PD2-200 is a plug-and-play unit that will replace the existing POD box on your UPS. It has four (4) IEC320-C19 and four (4) IEC320-C13 output connectors and is equipped with a Hardwire 3W + G(L-L-N-G) input connector. It also has circuit breakers and supports a max current of 63A.
| Design |
| Product colour |
Black |
| Type |
Single-phase |
| Ports & interfaces |
| AC outlet types |
C13 coupler, C19 coupler |
| AC outlets quantity |
8 AC outlet(s) |
| Power |
| Maximum current |
63 A |
| Certificates |
| Compliance certificates |
RoHS |
| Operational conditions |
| Operating altitude |
0 – 3000 m |
| Storage relative humidity (H-H) |
0 – 95% |
| Storage temperature (T-T) |
-20 – 60 °C |
| Operating temperature (T-T) |
0 – 40 °C |
| Weight & dimensions |
| Weight |
2 kg |
| Height |
145 mm |
| Width |
188 mm |
| Packaging data |
| Package height |
220 mm |
| Package depth |
522 mm |
| Package width |
302 mm |
| Package weight |
3 kg |
| General |
| Product family |
Liebert |
