TieDex UK NEC MultiSync ME431-MPi4 ME Series – 43″ LED-backlit LCD display – 4K – for digital signage
NEC MultiSync ME431-MPi4 – 43″ Diagonal Class ME Series LED-backlit LCD display – digital signage – 4K UHD (2160p) 3840 x 2160 – HDR – Direct LED – black, pantone 426M
Basic Specifications
- Manufacturer’s Part Number
- 60005372
- EAN
- 5028695122543
- Product Type
- LED-backlit LCD flat panel display
- Energy Class
- Class G
- Weight
- 13.9 kg
- Product Description
- NEC MultiSync ME431-MPi4 ME Series – 43″ LED-backlit LCD display – 4K – for digital signage
- Model
- NEC MultiSync ME431-MPi4
- Colour
- Black, pantone 426M
- Manufacturer Warranty
- 3-year warranty
- Dimensions (WxDxH)
- 97.3 cm x 6.26 cm x 56.12 cm
- HDMI Ports Qty
- 2 ports
- LCD Backlight Technology
- Direct LED local dimming
- Resolution
- 3840 x 2160
- Image Aspect Ratio
- 16:9
- Power Consumption Operational
- 80 Watt
- Display Format
- 4K UHD (2160p)
- USB
- Yes
- Voltage
- AC 120/230 V (50/60 Hz)
- Commercial Features
- SNMP support
- Diagonal Class
- 43″
- Included Accessories
- Remote control, 2 AAA batteries
- Power Consumption Stand by
- 0.5 Watt
- Connectivity
- LAN
- Video Interface
- HDMI
- Commercial Use
- Digital signage
- Environmental Standards
- ENERGY STAR Qualified
- Speaker System
- 2 speakers
- PC Interface
- HDMI, DisplayPort
- Technology
- IPS
- TV Tuner
- No tuner
- Frame Rate & Enhancement Technology
- 60 Hz Refresh Rate
- Smart
- No
- Display Resolution
- 4K Ultra HD (2160p)
- Manufacturer Guarantee
- 3 Years
- Picture Enhancements
- DICOM Simulated Gamma
- Storage Capacity
- 32GB eMMC
General
- Product Type
- LED-backlit LCD flat panel display
- Energy Class
- Class G
- Energy Class (HDR)
- Class G
- Power Consumption Operational
- 80 Watt
- Power Consumption SDR (On mode)
- 77 kWh/1000h
- Power Consumption HDR (On mode)
- 64 kWh/1000h
- Diagonal Class
- 43″
- Commercial Use
- Yes – digital signage
- Series
- ME Series
- HDR Capable
- Yes
- TV Tuner
- No tuner
- TV Tuner Presence
- No
- Sensors
- Temperature sensor
- Video Interface
- HDMI
- HDMI Ports Qty
- 2 ports
- PC Interface
- HDMI, DisplayPort
- Modes
- Portrait mode, landscape mode, Eco mode, power saving mode
- Picture Enhancements
- DICOM Simulated Gamma
- Width
- 97.3 cm
- Depth
- 6.26 cm
- Height
- 56.12 cm
- Weight
- 13.9 kg
- Enclosure Colour
- Black, pantone 426M
Power
- Power Device
- Power supply
- Input Voltage
- AC 120/230 V (50/60 Hz)
- Power Consumption Stand by
- 0.5 Watt
Dimensions & Weight (Shipping)
- Width (Shipping)
- 112 cm
- Depth (Shipping)
- 20.3 cm
- Height (Shipping)
- 70 cm
- Weight (Shipping)
- 19.6 kg
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 20 – 80%
Miscellaneous
- Included Accessories
- 2 AAA batteries
- Cables Included
- HDMI cable
- Compliant Standards
- VESA DPMS, VESA FDMI, IP5X, UL 94-5VB, ISO 9241-307 Class 1, IP2X, HDCP
Manufacturer Warranty
- Service & Support
- Limited warranty – 3 years ¦ Limited warranty – backlight – 3 years
Sustainability Information
- ENERGY STAR Certified
- Yes
- ENERGY STAR Version
- 8.0
Network & Internet Multimedia
- Connectivity
- LAN
- LAN Protocol
- Fast Ethernet
Stands & Mounts
- Flat Panel Mount Interface
- 200 x 200 mm
- VESA Compatibility
- Yes
Connections
- Connector Type
- DisplayPort input ¦ 2 x HDMI input ¦ Remote control ¦ RS-232 input ¦ LAN ¦ USB 2.0 ¦ Audio line-out
Remote Control
- Type
- Remote control
Audio System
- Speaker System
- 2 speakers
- Output Power / Total
- 20 Watt
- Speakers
- 2 – 10 Watt
Media Player
- Supported Video Formats
- MPEG-2, WMV, AVI, MKV, MOV, VOB, M4V, MPG, MPEG, H.265, VP9, VP8, M4K
- Supported Audio Formats
- MP3, AC3, AAC
- Supported Pictures Formats
- JPG, PNG, JPEG
- USB Port
- Yes
- USB Ports Qty
- 1
- Configuration
- 32GB eMMC
Video Features
- Supported Computer Resolutions
- 1366 x 768, 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1280 x 720, 1360 x 768, 1920 x 1080, 1440 x 900, 1400 x 1050, 3840 x 2160, 4096 x 2160, 1650 x 1050, 1900 x 1200
Display
- LCD Display Technology
- IPS
- Resolution
- 3840 x 2160
- Display Format
- 4K UHD (2160p)
- Image Aspect Ratio
- 16:9
- Frame Rate & Enhancement Technology
- 60 Hz Refresh Rate
- LCD Backlight Technology
- Direct LED – local dimming
- Coating
- 1% haze
- Image Contrast Ratio
- 8000:1
- Brightness
- 400 cd/m²
- Viewing Angle
- 178 degrees
- Viewing Angle (Vertical)
- 178 degrees
- Response Time
- 8 ms
- Commercial Features
- SNMP support
- Operation Hours / Days
- 18 / 7
- Features
- Aspect ratio control (ARC), automatic alarm e-mails, NaViSet Administrator 2, AMX NetLinx support, PJLink, ASCII Control Commands, emergency notification, removable logo, CEC Support, Raspberry Pi Compute Module 4 Compatible, scheduled timer
Environmental Standards
- ENERGY STAR Certified
- Yes
- ENERGY STAR Version
- 8.0
