Logitech MeetUp 2 – USB conference camera
AI-driven experiences in small USB rooms
Meetup 2 brings intelligent audio and video experiences to USB-based deployments in small rooms. Watch your MeetUp 2 get more capable through regular updates that improve performance, add capabilities, and deepen integrations.
Simple to manage and deploy at scale
MeetUp 2 is easy to set up and manage in small spaces thanks to multiple mounting options, clean cabling, and remote management through Logitech Sync.
Single cable BYOD
Deliver elegant, single-cable BYOD connections with MeetUp 2 when it is paired with the optional Active USB Cable accessory.
| Technical specifications | |
|---|---|
| Overview | Built-in Components 6 DMIC microphone array Digital PTZ camera 1 full range ported speaker Cable management & retention system Multi-mount Logitech CollabOS platform Logitech RightSight 2 Logitech RightSound 2 |
| General specifications | Enclosure: All-in-one enclosure Device Management: Logitech Sync Displays Supported: BYOD mode: 1; Dedicated computer mode: computer/application dependent Display Resolution: 1080p Network Protocol Support: IPv4, IPv6 Proxy Support: IP based Proxy, FQDN based Proxy, Proxy using PAC file |
| Camera | Digital pan: ±48° at 4x zoom Digital Tilt: ±32° at 4x zoom Zoom: 4X HD digital zoom Diagonal Field of View: 120° Horizontal Field of View: 113° Vertical Field of View: 80° Resolution: 4K |
| Speakers | Driver: 55 mm with bass reflex enclosure and patented suspension design Sensitivity: 83 dB SPL @1W +/-2dB @ 1 meter Rated Power: 8W THD at 1W, 1kHz : <2% Speaker Sampling Rate: 48KHz Impedance: 4 Ohms |
| Microphones | Frequency Response: 90Hz – 16kHz Sensitivity: -36dBFS +/-1 dB @ 1Pa Microphone data rate output: 48 kHz Pickup Range: Up to 7m Beamforming Elements: Six omnidirectional digital MEMS microphones forming five adaptive acoustic broadside beams Audio processing: AEC (Acoustic Echo Cancellation) VAD (Voice Activity Detector) Noise suppression: AI based de-noising algorithm |
| Interfaces | HDMI Out: 1 HDMI In: 1 USB: 1 x Type C USB 3.1 Network: 10/100/1G Ethernet WiFi: 802.11a/b/g/n/ac Bluetooth: Bluetooth® Low Energy |
| Power and cables | Power supply: Auto-sensing Operating Voltage/Power: 100-240V, 19V, 2.1A Power Supply Dimensions: 114 x 47 mm x 32.3 mm DC Cable: 3 m USB C to USB C 3.0 Cable: 3 m |
| Environmental | Operating temperature: 0 to 40°C Storage temperature: -25-70°C Humidity: 10 to 90% |
| Security | File Based Encryption: AES-128 Data Encryption: Symmetric Keys, PKI Device Identity: Protected by device attestation Device Access: Authenticated using API Key Protection: Arm TrustZone, RPMP Physical Security: Kensington security slot |
MeetUp 2
Buy All-in-one USB conference camera for huddle and small rooms.
AI-driven experiences in small USB rooms
Meetup 2 brings intelligent audio and video experiences to USB-based deployments in small rooms. Watch your MeetUp 2 get more capable through regular updates that improve performance, add capabilities, and deepen integrations.
Simple to manage and deploy at scale
MeetUp 2 is easy to set up and manage in small spaces thanks to multiple mounting options, clean cabling, and remote management through Logitech Sync.
Single cable BYOD
Deliver elegant, single-cable BYOD connections with MeetUp 2 when it is paired with the optional Active USB Cable accessory.
Specifications
| Technical specifications | |
|---|---|
| Overview | Built-in Components 6 DMIC microphone array Digital PTZ camera 1 full range ported speaker Cable management & retention system Multi-mount Logitech CollabOS platform Logitech RightSight 2 Logitech RightSound 2 |
| General specifications | Enclosure: All-in-one enclosure Device Management: Logitech Sync Displays Supported: BYOD mode: 1; Dedicated computer mode: computer/application dependent Display Resolution: 1080p Network Protocol Support: IPv4, IPv6 Proxy Support: IP based Proxy, FQDN based Proxy, Proxy using PAC file |
| Camera | Digital pan: ±48° at 4x zoom Digital Tilt: ±32° at 4x zoom Zoom: 4X HD digital zoom Diagonal Field of View: 120° Horizontal Field of View: 113° Vertical Field of View: 80° Resolution: 4K |
| Speakers | Driver: 55 mm with bass reflex enclosure and patented suspension design Sensitivity: 83 dB SPL @1W +/-2dB @ 1 meter Rated Power: 8W THD at 1W, 1kHz : <2% Speaker Sampling Rate: 48KHz Impedance: 4 Ohms |
| Microphones | Frequency Response: 90Hz – 16kHz Sensitivity: -36dBFS +/-1 dB @ 1Pa Microphone data rate output: 48 kHz Pickup Range: Up to 7m Beamforming Elements: Six omnidirectional digital MEMS microphones forming five adaptive acoustic broadside beams Audio processing: AEC (Acoustic Echo Cancellation) VAD (Voice Activity Detector) Noise suppression: AI based de-noising algorithm |
| Interfaces | HDMI Out: 1 HDMI In: 1 USB: 1 x Type C USB 3.1 Network: 10/100/1G Ethernet WiFi: 802.11a/b/g/n/ac Bluetooth: Bluetooth® Low Energy |
| Power and cables | Power supply: Auto-sensing Operating Voltage/Power: 100-240V, 19V, 2.1A Power Supply Dimensions: 114 x 47 mm x 32.3 mm DC Cable: 3 m USB C to USB C 3.0 Cable: 3 m |
| Environmental | Operating temperature: 0 to 40°C Storage temperature: -25-70°C Humidity: 10 to 90% |
| Security | File Based Encryption: AES-128 Data Encryption: Symmetric Keys, PKI Device Identity: Protected by device attestation Device Access: Authenticated using API Key Protection: Arm TrustZone, RPMP Physical Security: Kensington security slot |
Basic Specifications
- Manufacturer’s Part Number
- 960-001681
- EAN
- 0097855198198
- Networking
- Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, Bluetooth LE
- Video Input
- Digital video camera – SuperSpeed USB 3.0
- Power
- AC 100-240 V
- Model
- Logitech MeetUp 2
- System Requirements
- Microsoft Windows 10 or later, Apple MacOS
- Device Type
- USB conference camera
- Dimensions (WxDxH)
- 46.92 cm x 7.3 cm x 7.33 cm
- Manufacturer Warranty
- 2-year warranty
- Weight
- 1.8 kg
- Audio Output
- Speaker(s)
- Product Description
- Logitech MeetUp 2
- Audio Input
- 6-microphone array – omni-directional, beamforming
Networking
- Connectivity Technology
- Wired, wireless
- Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, Bluetooth LE
- Network / Transport Protocol
- IPv4, IPv6
- Features
- Cable management, IP proxy, FQDN proxy, PAC file proxy, Public Key Infrastructure (PKI), ARM TrustZone, security slot (Kensington security lock compatible), AES encryption
Expansion / Connectivity
- Interfaces
- 1 x audio / video – HDMI input ¦ 1 x audio / video – HDMI output ¦ 1 x network – Ethernet 10Base-T/100Base-TX/1000Base-T – RJ-45 ¦ 1 x USB-C 3.1 – 24 pin USB-C
Video Input
- Type
- Digital video camera (colour) – desktop
- Interface Type
- SuperSpeed USB 3.0
- Digital Video Capture Resolution
- 3840 x 2160
<
