TieDex UK LG 22XE1J 22″ Class (21.5″ viewable) with Integrated Pro:Idiom LED-backlit LCD display – Full HD – outdoor – for digital signage
LG 22XE1J – 22″ Diagonal Class (21.5″ viewable) LED-backlit LCD display – digital signage with Integrated Pro:Idiom outdoor – full sun – webOS – 1080p 1920 x 1080 – Edge LED – black
Basic Specifications
- Manufacturer’s Part Number
- 22XE1J
- EAN
- 8806091435774
- Product Type
- LED-backlit LCD flat panel display with Integrated Pro:Idiom – outdoor
- Product Description
- LG 22XE1J 22″ Class (21.5″ viewable) with Integrated Pro:Idiom LED-backlit LCD display – Full HD – outdoor – for digital signage
- HDMI Ports Qty
- 1 ports
- LCD Backlight Technology
- LED backlight – Edge LED
- Resolution
- 1920 x 1080
- Image Aspect Ratio
- 16:9
- Power Consumption Operational
- 85 Watt
- Model
- LG 22XE1J
- Speaker System
- 2 speakers
- Dimensions (WxDxH) – without stand
- 55.73 cm x 6.6 cm x 31.98 cm
- Display Format
- 1080p
- Energy Class
- Class C
- Energy Consumption per Year
- 53 kWh
- USB
- Yes
- Diagonal Class
- 22″
- Video Interface
- HDMI
- Commercial Use
- Digital signage
- Voltage
- AC 100-240 V (50/60 Hz)
- Technology
- IPS
- Colour
- Black
- TV Tuner
- No tuner
- Weight
- 8.7 kg
- Power Consumption (On mode)
- 36 W
- Display Resolution
- Full HD (1080p)
- Diagonal Size
- 21.5″
- Connectivity
- Wi-Fi, LAN, Bluetooth
- Platform
- webOS
- Picture Enhancements
- Smart Brightness Control, 72% Colour Gamut NTSC
- Storage Capacity
- 16 GB
- Commercial Features
- SNMP support, Sync Mode, Smart Platform, Integrated Contents Management System (CMS), SuperSign CMS compatible, SuperSign Control+ compatible, SuperSign Control compatible, Visible with Polarised Sunglasses, Real Time Communication (webRTC), FailOver, LG ConnectedCare, Video Tag, booting logo image, SI Server Setting, Network Ready
- Included Accessories
- Remote control
- Power Consumption Stand by
- 0.5 Watt
- Sun Exposure
- Full sun
- Frame Rate & Enhancement Technology
- 60 Hz Refresh Rate
Environmental Parameters
- Min Operating Temperature
- -30 °C
- Max Operating Temperature
- 50 °C
- Humidity Range Operating
- 5 – 100%
Remote Control
- Type
- Remote control
- Battery Included
- Yes
- Battery Included Qty
- 2
Audio System
- Speaker System
- 2 speakers
- External Speakers Amplifier Power (Total)
- 20 Watt
- Features
- Gapless playback
- Speakers
- 2 x speaker – 10 Watt
Stands & Mounts
- Flat Panel Mount Interface
- 100 x 100 mm
- VESA Compatibility
- Yes
Media Player
- USB Port
- Yes
- USB Ports Qty
- 1
- Configuration
- Quad-Core 16 GB
Connections
- Connector Type
- RS-232C input ¦ LAN ¦ External speaker ¦ HDMI input ¦ USB 2.0
Display
- LCD Display Technology
- IPS
- LED Lifetime
- 50000 hours
- Colour Support
- 16700000 colours
- Resolution
- 1920 x 1080
- Display Format
- 1080p
- Image Aspect Ratio
- 16:9
- Frame Rate & Enhancement Technology
- 60 Hz Refresh Rate
- LCD Backlight Technology
- LED backlight – Edge LED
- Coating
- Anti-glare, conformal, Quarter Wave Plate (QWP), 25% haze
- Image Contrast Ratio
- 1000:1
- Dynamic Contrast Ratio
- 800000:1
- Brightness
- 1500 cd/m²
- Response Time
- 25 ms
- Commercial Features
- SNMP support, Sync Mode, Smart Platform, Integrated Contents Management System (CMS), SuperSign CMS compatible, SuperSign Control+ compatible, SuperSign Control compatible, Visible with Polarised Sunglasses, Real Time Communication (webRTC), FailOver, LG ConnectedCare, Video Tag, booting logo image, SI Server Setting, Network Ready
- Operation Hours / Days
- 24 / 7
- Features
- Image Sticking Minimization (ISM), Auto Brightness Control, Direct Sunlight, BEACON technology, 8-bit support
General
- Product Type
- LED-backlit LCD flat panel display with Integrated Pro:Idiom
- Energy Class
- Class C
- Power Consumption (Max)
- 115 Watt
- Power Consumption Operational
- 85 Watt
- Power Consumption (On mode)
- 36 W
- Energy Consumption per Year
- 53 kWh
- Diagonal Class
- 22″
- Diagonal Size
- 21.5″
- Commercial Use
- Yes – digital signage
- Outdoor
- Yes
- Sun Exposure
- Full sun
- Platform
- webOS
- Operating System
- webOS 4.1
- TV Tuner
- No tuner
- TV Tuner Presence
- No
- Sensors
- Temperature sensor, brightness sensor, acceleration sensor, humidity sensor
- Video Interface
- HDMI
- HDMI Ports Qty
- 1 ports
- Modes
- Portrait mode, landscape mode
- Picture Enhancements
- Smart Brightness Control, 72% Colour Gamut NTSC
- Protection
- Dustproof, water-resistant, shatter-resistant, snowproof
- Dimensions
- Without stand
- Width
- 55.73 cm
- Depth
- 6.6 cm
- Height
- 31.98 cm
- Weight
- 8.7 kg
- Enclosure Colour
- Black
Miscellaneous
- Cables Included
- RS-232C cable
- Compliant Standards
- FCC Class A certified, VCCI, CB, CEC, KC, ERP, NRTL, HDCP 1.4, IP56
Power
- Power Device
- Power supply
- Input Voltage
- AC 100-240 V (50/60 Hz)
- Power Consumption Stand by
- 0.5 Watt
- Power Consumption (Off Mode)
- 0.5 Watt
Dimensions & Weight (Shipping)
- Width (Shipping)
- 63.2 cm
- Depth (Shipping)
- 18.7 cm
- Height (Shipping)
- 39.4 cm
- Weight (Shipping)
- 10 kg
Network & Internet Multimedia
- Connectivity
- Wi-Fi, LAN, Bluetooth
- LAN Protocol
- Ethernet
