TieDex UK Cisco Catalyst 9300 – Network Essentials – switch – 48 ports – Managed – rack-mountable
Cisco Catalyst 9300 – Network Essentials – switch – L3 – Managed – 48 x 10/100/1000 (PoE+) – rack-mountable – PoE+ (437 W)
Basic Specifications
- Manufacturer’s Part Number
- C9300-48P-E
- EAN
- 8592978090180
- Manufacturer Warranty
- Limited lifetime warranty
- Weight
- 7.59 kg
- Product Description
- Cisco Catalyst 9300 – Network Essentials – switch – 48 ports – Managed – rack-mountable
- Model
- Cisco Catalyst 9300
- Dimensions (WxDxH)
- 44.5 cm x 44.5 cm x 4.4 cm
- Features
- Trunking, full duplex mode, WRED, STP support, ACL support, QoS, RSPAN, MIB, Cisco StackWise-480 technology, Cisco StackPower technology, FNF, 802.1x authentication, 16MB packet buffer, FTP client, 3 fans, CoPP, SSM, integrated Wireshark, VLAN Double Tagging (Q-in-Q), Private VLAN
- Device Type
- Switch – 48 ports – L3 – Managed – stackable
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at
- Capacity
- IPv4 routing table entries: 32000 ¦ IPv6 routing table entries: 16000 ¦ Flexible NetFlow entries: 64000 ¦ VLAN IDs: 4000 ¦ Switched virtual interfaces (SVIs): 2000
- MAC Address Table Size
- 32000 entries
- Subtype
- Gigabit Ethernet
- Performance
- Switching capacity: 128 Gbps ¦ Stacking bandwidth: 480 Gbps ¦ Forwarding rate: 190.48 Mpps
- Power Redundancy
- Optional
- Enclosure Type
- Rack-mountable 1U
- Routing Protocol
- OSPF, IS-IS, RIP-1, RIP-2, IGMP, VRRP, PIM-SM, OSPFv3, PIM-SSM, policy-based routing (PBR), RIPng
- Remote Management Protocol
- SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF
- Jumbo Frame Support
- 9198 bytes
- Ports
- 48 x 10/100/1000 (PoE+)
- PoE Budget
- 437 W
- Power Over Ethernet (PoE)
- PoE+
General
- Device Type
- Switch – 48 ports – L3 – Managed – stackable
- Enclosure Type
- Rack-mountable 1U
- Subtype
- Gigabit Ethernet
- Ports
- 48 x 10/100/1000 (PoE+)
- Power Over Ethernet (PoE)
- PoE+
- PoE Budget
- 437 W
- Performance
- Switching capacity: 128 Gbps ¦ Stacking bandwidth: 480 Gbps ¦ Forwarding rate: 190.48 Mpps
- Capacity
- IPv4 routing table entries: 32000 ¦ IPv6 routing table entries: 16000 ¦ Flexible NetFlow entries: 64000 ¦ VLAN IDs: 4000 ¦ Switched virtual interfaces (SVIs): 2000
- MAC Address Table Size
- 32000 entries
- Jumbo Frame Support
- 9198 bytes
- Routing Protocol
- OSPF, IS-IS, RIP-1, RIP-2, IGMP, VRRP, PIM-SM, OSPFv3, PIM-SSM, policy-based routing (PBR), RIPng
- Remote Management Protocol
- SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF
- Encryption Algorithm
- 128-bit AES
- Features
- Trunking, full duplex mode, WRED, STP support, ACL support, QoS, RSPAN, MIB, Cisco StackWise-480 technology, Cisco StackPower technology, FNF, 802.1x authentication, 16MB packet buffer, FTP client, 3 fans, CoPP, SSM, integrated Wireshark, VLAN Double Tagging (Q-in-Q), Private VLAN
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at
- RAM
- 8 GB
- Flash Memory
- 16 GB
- Status Indicators
- Status
Dimensions & Weight
- Width
- 44.5 cm
- Depth
- 44.5 cm
- Height
- 4.4 cm
- Weight
- 7.59 kg
Miscellaneous
- MTBF
- 277,770 hours
- Compliant Standards
- CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN50082-1, EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, CCC, ICES-003 Class A, EN 61000-4-5, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, AS/NZS 3548 Class A, BSMI Class A, VCCI Class A, EN 55022 Class A, FCC CFR47 Part 15 A, EN 300 386, TVCN 7317, VCCI V-3/2009 Class A, CAN/CSA-C22.2 No. 60950-1
Manufacturer Warranty
- Service & Support
- Limited warranty – replacement – lifetime – response time: next business day ¦ Technical support – consulting – 90 days
Expansion / Connectivity
- Interfaces
- 48 x 1000Base-T RJ-45 PoE+ ¦ 1 x USB 2.0
- Expansion Slots
- 1 (total) / 1 (free) x Expansion Slot
Power
- Power Device
- Internal power supply – hot-plug
- Installed Qty
- 1
- Max Supported Qty
- 2
- Power Redundancy
- Optional
- Power Provided
- 715 Watt
Environmental Parameters
- Min Operating Temperature
- -5 °C
- Max Operating Temperature
- 45 °C
- Humidity Range Operating
- 5 – 90% (non-condensing)
- Min Storage Temperature
- -40 °C
- Max Storage Temperature
- 70 °C
- Humidity Range Storage
- 5 – 90% (non-condensing)
Software / System Requirements
- Software Included
- Cisco IOS Universal
