StarTech.com Desk Mount Quad Monitor Arm – Premium Articulating VESA 4 Monitor Mount 2×2 up to 30″ – Ergonomic Height Adjustable Pole Mount – Tilt/Swivel/Rotate – C-Clamp/Grommet – Silver
- HEAVY DUTY MULTI-MONITOR MOUNT: VESA 75×75/100x100mm compatible desk mount quad monitor arm (2×2) supports 4 large displays up to 30″ (24.8lb) per screen; Articulating & height adjustable
- EASY INSTALLATION: Premium desktop quad monitor mount w/ convenient toolless slide & click design makes assembling the monitor arms & VESA adapters easy; Desk & grommet clamps can be tightened by hand
- WIDE RANGE OF MOTION: Ergonomic monitor mount w/ +90°/-15° tilt, +/-180° swivel, 360° rotation, adjustable height along 27.9″ pole; Swiveling arms for flexible LCD/LED monitor setup ie. back to back
- ADJUSTABLE SET UP: Silver four monitor mount w/ cable management clips along arms & center pole to organize cables for a tidy computer workspace & holds incl. adjustment tools for articulation tension
- STARTECH.COM ADVANTAGE: IT professionals choice for over 30 years; This quad monitor arm is backed for 10-years by StarTech.com, including free 24/5 North America based multi-lingual tech support
Four Monitor Mount | Desk/Grommet Mount | Tool-less Assembly | For Up to 30″ Monitors
Create a highly productive ergonomic workspace with this premium quad monitor mount, supporting four monitors up to 30″ each. Four articulating monitor arms feature dual-swivel action, providing a wide range of motion side to side. The attractive silver finish enhances the aesthetics of your workspace.
Enjoy a Wide Range of Motion with Four Displays
The articulating monitor mount lets you maximize your productivity and work in comfort. Each of the four articulating monitor arms extends a full 16.5″ (420 mm) and offer a wide range of motion on several axes. Adjust the position of each screen effortlessly as you work.
Sleek and Stable Aluminum Design
Made of robust aluminum, the four-monitor setup provides stable support for VESA compatible monitors (75×75, 100×100) with a weight capacity of up to 24.8 lb. (11.25 kg) per display. The cable-management channel helps to keep your workstation neat and tidy.
Adjust your Viewing Angle
Share your screen with ease. The four arm monitor mount offers a full +180-degree / -180-degree pan, to move your screen left or right. It tilts freely +90 / -15 degrees to adjust the angle up or down. Rotate your screens for landscape or portrait viewing.
Height Adjustment
Work in comfort. This height adjustable monitor mount lets you raise or lower the monitor arms along the 708 mm (27.9″) pole.
Tool-less Assembly
The fully assembled desk clamp and pole, plus quick slide-and-click connections, ensure easy assembly. It also saves time when setting up multiple units. The four screen mount gives you the option of desk clamp or grommet hole mounting (hardware included).
The TAA compliant ARMQUADPS is backed by a StarTech.com 10-year warranty and free lifetime technical support.
The StarTech.com Advantage
| Mounting | |
|---|---|
| Desk thickness (max) | 6 cm |
| Desk thickness (min) | 2 cm |
| Extension arm (max) | 42 cm |
| Number of displays supported | 4 |
| Maximum VESA mount | 100 x 100 mm |
| Minimum VESA mount | 75 x 75 mm |
| Mounting | Clamp |
| Maximum weight capacity (per display) | 11.25 kg |
| Mounting type | Desk |
| Maximum screen size | 68.6 cm (27″) |
| Minimum screen size | 33 cm (13″) |
| Maximum weight capacity | 45 kg |
| Ergonomics | |
|---|---|
| Cable management | Yes |
| Angle of rotation | 360° |
| Swivel angle range | -180 – 180° |
| Tilt angle range | -15 – 90° |
| Height adjustment | Yes |
| Design | |
|---|---|
| Housing material | Aluminium |
| Product colour | Silver |
| Weight & dimensions | |
|---|---|
| Weight | 9.5 kg |
| Height | 910 mm |
| Depth | 420 mm |
| Width | 940 mm |
| Packaging data | |
|---|---|
| Package weight | 12.7 kg |
| Package height | 345 mm |
| Package depth | 885 mm |
| Package width | 270 mm |
| Packaging content | |
|---|---|
| Manual | Yes |
| Number of screws | 26 |
| Screws included | Yes |
| Number of cable clips | 4 |
| VESA mount included | Yes |
| Clamp included | Yes |
| Wrench type | Hexagonal wrench |
| Wrench included | Yes |
| Other features | |
|---|---|
| Certification | CE, TAA, REACH |
| Compliance certificates | RoHS |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 85299097 |
| Products per master (outer) case | 1 pc(s) |
| Master (outer) case height | 345 mm |
| Master (outer) case length | 885 mm |
| Master (outer) case width | 270 mm |
