MSI RX 6750 XT MECH 2X 12G V1 AMD Radeon RX 6750 XT 12 GB GDDR6
- Up to 2600 MHz / 18 Gbps
- 12GB GDDR6
- DisplayPort x 3 (v1.4)
- HDMI™ x 1 (Supports 4K@120Hz/8K@60Hz and VRR as specified in HDMI™ 2.1)
- TORX Fan 3.0: The award-winning MSI TORX Fan 3.0 design creates high static pressure and pushes the limits of thermal performance
- Supports multi-GPU setups
- OC Scanner: An automated function finds the highest stable overclock settings
- On Screen Display: Provides real-time information of your system’s performance
- Predator: In-game video recording
Radeon RX 6000 MECH SERIES
ARM YOURSELF FOR THE FINAL BLOW
MECH brings a performance-focused design that maintains the essentials to accomplish any task at hand.
Rocking a trusted dual fan arrangement laid into a rigid industrial design lets this sharp looking graphics card fit into any build.
BACKPLATE
A clean-looking brushed-finish backplate reinforces the length of the card.
TOUGH ENOUGH TO
BACK YOU UP!
MECH has been crafted to serve you well during intense gameplay. This legendary item has extra power unlocked through the Custom PCB.
BETTER SAFE THAN SORRY
Additional fuses built into the custom PCB provide additional safeguards against electrical damage.
FORGED FROM ENHANCED MATERIALS
An enhanced PCB material design with 2oz thickened copper increases conductivity, improving heat dissipation, and high-performance reliability.
TAILORED PCB DESIGN
Not all circuit boards are created equal. A custom PCB Design provides greater reliability and beefed up power circuitry for pushing the card to its limits.
Bringing It All Together
MSI’s exclusive MSI Center software helps you get the most out of your MSI products. Monitor, tweak and optimize in real-time with just a few clicks.
| Processor | |
|---|---|
| Parallel processing technology support | Not supported |
| Stream processors | 2560 |
| Maximum displays per videocard | 4 |
| Processor boost clock speed (Gaming mode) | 2495 MHz |
| Processor boost clock speed | 2600 MHz |
| CUDA | No |
| Maximum resolution | 7680 x 4320 pixels |
| Graphics processor | Radeon RX 6750 XT |
| Graphics processor family | AMD |
| Memory | |
|---|---|
| Data transfer rate | 18 Gbit/s |
| Memory bus | 192 bit |
| Graphics card memory type | GDDR6 |
| Discrete graphics card memory | 12 GB |
| Ports & interfaces | |
|---|---|
| DisplayPort version | 1.4 |
| HDMI version | 2.1 |
| DisplayPorts quantity | 3 |
| HDMI ports quantity | 1 |
| Interface type | PCI Express 4.0 |
| Performance | |
|---|---|
| Dual Link DVI | No |
| HDCP | Yes |
| Virtual Reality (VR) ready | Yes |
| OpenGL version | 4.6 |
| DirectX version | 12.0 |
| TV tuner integrated | No |
| Design | |
|---|---|
| Product colour | Black, Silver |
| Form factor | Full-Height/Half-Length (FH/HL) |
| Number of fans | 2 fan(s) |
| Cooling technology | MSI TORX Fan 3.0 |
| Cooling type | Active |
| Power | |
|---|---|
| Supplementary power connectors | 2x 8-pin |
| Power consumption (typical) | 250 W |
| Minimum system power supply | 650 W |
| Weight & dimensions | |
|---|---|
| Height | 132 mm |
| Depth | 52 mm |
| Length | 249 mm |
| Weight | 961 g |
| Packaging data | |
|---|---|
| Package type | Box |
| Package weight | 1.41 kg |
