Lenovo 4XB7A17101 internal solid state drive 480 GB 2.5″ Serial ATA III TLC
- 480 GB 2.5″ Serial ATA III
- 79000 IOPS
- 30000 IOPS
- TLC
- Hardware encryption AES
- Component for: Server/workstation
The ThinkSystem S4520 Read Intensive SATA SSDs use 144-layer Intel 3D NAND TLC Flash Memory technology with a 6Gbps SATA interface to provide an affordable solution with industry leading performance.
This product guide provides essential presales information to understand the S4520 SSDs, their key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about S4520 SSDs and consider their use in IT solutions.
| Features | |
|---|---|
| Mean time between failures (MTBF) | 2000000 h |
| Hot-swap | Yes |
| Random write (4KB) | 30000 IOPS |
| Random read (4KB) | 79000 IOPS |
| Security algorithms | AES |
| Hardware encryption | Yes |
| Component for | Server/workstation |
| Memory type | TLC |
| Interface | Serial ATA III |
| SSD form factor | 2.5″ |
| SSD capacity | 480 GB |
| Power | |
|---|---|
| Power consumption (max) | 3 W |
| Weight & dimensions | |
|---|---|
| Weight | 70 g |
| Height | 7 mm |
| Depth | 100 mm |
| Width | 70 mm |
| Packaging data | |
|---|---|
| Package weight | 434 g |
| Package height | 63 mm |
| Package depth | 133 mm |
| Package width | 174 mm |
| Operational conditions | |
|---|---|
| Operating relative humidity (H-H) | 5 – 95% |
| Operating temperature (T-T) | 0 – 70 °C |
| Other features | |
|---|---|
| Compatible products | ThinkSystem S4520 |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 84717070 |
