Kingston Technology KSM32RD8/32HCR memory module 32 GB 1 x 32 GB DDR4 3200 MHz ECC
- 16 internal banks
- Data transfer rates: PC4-3200, PC4-2933, PC4-2666, PC4-2400, PC4-2133, PC4-1866, PC4-1600
- Bi-Directional Differential Data Strobe
- 8 bit pre-fetch
- Supports ECC error correction and detection
- On-Die Termination (ODT)
- Temperature sensor with integrated SPD
- This product is in compliance with the RoHS directive
Kingston makes it quick and easy to select compatible RAM memory for your Desktop PC, Laptop, or Server.
| Features |
| JEDEC standard |
Yes |
| Lead plating |
Gold |
| Programming power voltage (VPP) |
2.5 V |
| Row active time |
32 ns |
| Refresh row cycle time |
350 ns |
| Row cycle time |
45.75 ns |
| Module configuration |
4096M x 64 |
| Memory voltage |
1.2 V |
| Memory ranking |
2 |
| CAS latency |
22 |
| ECC |
Yes |
| Memory form factor |
288-pin DIMM |
| Component for |
PC/Server |
| Memory clock speed |
3200 MHz |
| Internal memory type |
DDR4 |
| Memory layout (modules x size) |
1 x 32 GB |
| Internal memory |
32 GB |
| Buffered memory type |
Registered (buffered) |
| Technical details |
| Compliance certificates |
RoHS |
| Weight & dimensions |
| Height |
31.2 mm |
| Width |
133.3 mm |
| Logistics data |
| Harmonized System (HS) code |
84733020 |
