Kensington SD5765T Thunderbolt™ 4 Dual 4K Docking Station – Designed for Surface
- Wired
- Host interface: Thunderbolt 4
- USB Power Delivery (USB PD)
- Ethernet LAN 10,1000,100 Mbit/s
- MicroSD (TransFlash), SD
- Plug and Play
Designed exclusively for Surface, the SD5765T Thunderbolt™ 4 Dual 4K Docking Station provides everything you need to enhance your productivity today and well into the future. Offering a true plug-and-play experience with no drivers or downloads required, the SD5765T supports Thunderbolt™ based Surface devices. Flexible port options include support for a Single 8K @ 60Hz with DSC enabled (via front TB4 port) or Dual 4K @ 60Hz (via 2 x HDMI® ports). Focused on productivity, the SD5765T supports up to 96W of dynamic Power Delivery, up to 40Gbps data transfer speeds, daisy chaining and includes 13 connectivity ports. Includes Kensington DockWorks™ Software and 3-year limited warranty.
Designed exclusively for Surface to provide a seamless dock and charge experience.
Enjoy peace of mind knowing your covered by Kensington with a professional 3-year limited warranty.
Plug-and-play solution with no drivers or downloads required.
Transfer up to 40Gbps of data, video and audio – all through the included 0.8m (2.6’) Thunderbolt™ 4 cable.
Up to Single 8K @ 60Hz via single TB4 port when DSC is enabled or Dual 4K @ 60Hz via 2 x HDMI ports for Thunderbolt™ 4-enabled devices.
Supports up to 96W of Power Delivery to host and connected accessories whenever and wherever it is needed.
2 x HDMI® ports, 1 x Thunderbolt™ 4 port, 1 x Thunderbolt™ 4 host port, 1 x USB-C® 3.2 Gen2 10Gbps port, 2 x USB-A 3.2 Gen2 10Gbps ports, 2 x USB-A 3.2 Gen1 5Gbps ports, 1 x Gigabit Ethernet port, 1 x audio combo jack and two UHS-II 4.0 SD/Micro SD card readers.
Built-in UHS-II SD and Micro SD card readers are perfect for graphic designers, video editors and animators requiring fast and efficient data transfer speeds.
Zero footprint mounting option maximises desktop space and reduces cable clutter by mounting your docking station out of the way.
Protect your investment with a Kensington cable lock (K65020EU or K65021WW, sold separately).
| Ports & interfaces |
| Headphone connectivity |
3.5 mm |
| Headphone outputs |
1 |
| Combo headphone/mic port |
Yes |
| Thunderbolt 4 ports quantity |
2 |
| HDMI version |
2.0 |
| HDMI ports quantity |
2 |
| USB Power Delivery up to |
96 W |
| USB Power Delivery (USB PD) |
Yes |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| Host interface |
Thunderbolt 4 |
| Connectivity technology |
Wired |
| Network |
| Ethernet LAN data rates |
10,1000,100 Mbit/s |
| Ethernet LAN (RJ-45) ports |
1 |
| Ethernet LAN |
Yes |
| Performance |
| Plug and Play |
Yes |
| Cable lock slot type |
Kensington |
| Number of displays supported |
2 |
| HD type |
8K Ultra HD |
| Data transfer rate |
40 Gbit/s |
| Compatible memory cards |
MicroSD (TransFlash), SD |
| Card reader integrated |
Yes |
| Product colour |
Grey |
| Software |
| Windows operating systems supported |
Yes |
| Packaging data |
| Package weight |
1.96 kg |
| Package height |
105 mm |
| Package depth |
240 mm |
| Package width |
170 mm |
| Quantity per pack |
1 pc(s) |
| Other features |
| USB ports quantity |
6 |
| Compatible operating systems |
Windows 10 or above |
