Intel Xeon X5650 processor 2.66 GHz 12 MB Smart Cache
- Intel® Xeon® 5000 Sequence X5650 2.66 GHz
- 12 MB Smart Cache LGA 1366 (Socket B)
- Processor cores: 6 32 nm 64-bit 95 W
- Maximum internal memory supported by processor: 288 GB DDR3-SDRAM
Intel Xeon processors represent a broad product line to meet a range of demanding performance and energy efficiency requirements for compute-intensive embedded, storage, and communications applications.on processor is ideal for compute intensive and heavy workload applications that require floating-point performance and the intense use of graphics for design. The Intel Xeon processor features a 400 MHz front side bus, dual channel RDRAM memory and the Intel 860 chipset, which provides the bandwidth and performance throughput to deliver streaming audio/video and online collaboration. For your demanding application needs, Intel Xeon processor-based workstations provide the ideal solution.The Intel Xeon processor at 2 GHz is designed for dual-processing performance workstations. The processor is binary compatible with previous generation Intel Architecture processors.
| Processor | |
|---|---|
| Processor ARK ID | 47922 |
| Processor code | SLBV3 |
| Processor codename | Westmere EP |
| Processor system type | DP |
| Memory bandwidth supported by processor (max) | 32 GB/s |
| Number of QPI links | 2 |
| CPU multiplier (bus/core ratio) | 20 |
| Bus type | QPI |
| Stepping | B1 |
| VID Voltage Range | 0.75 – 1.35 V |
| Thermal Design Power (TDP) | 95 W |
| Processor cache type | Smart Cache |
| Processor cache | 12 MB |
| Processor boost frequency | 3.06 GHz |
| Processor operating modes | 64-bit |
| System bus rate | 6.4 GT/s |
| Processor threads | 12 |
| Processor series | Intel Xeon 5600 Series |
| Component for | Server/workstation |
| Cooler included | No |
| Box | No |
| Processor lithography | 32 nm |
| Processor socket | LGA 1366 (Socket B) |
| Processor cores | 6 |
| Processor base frequency | 2.66 GHz |
| Processor model | X5650 |
| Processor family | Intel® Xeon® 5000 Sequence |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| ECC | Yes |
| Memory channels | Triple-channel |
| Memory clock speeds supported by processor | 800,1066,1333 MHz |
| Memory types supported by processor | DDR3-SDRAM |
| Maximum internal memory supported by processor | 288 GB |
| Graphics | |
|---|---|
| On-board graphics card | No |
| Features | |
|---|---|
| Commodity Classification Automated Tracking System (CCATS) | G077159 |
| Export Control Classification Number (ECCN) | 5A992C |
| Embedded options available | No |
| CPU configuration (max) | 2 |
| Supported instruction sets | SSE4.2 |
| Market segment | Server |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | No |
| Processor special features | |
|---|---|
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Demand Based Switching | Yes |
| Intel Enhanced Halt State | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 1.0 |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Trusted Execution Technology | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| General | |
|---|---|
| Product family | Xeon |
| Operational conditions | |
|---|---|
| Tcase | 81.3 °C |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 8542310001 |
| Technical details | |
|---|---|
| Bus bandwidth | 6.4 |
| Bus type units | GT/s |
| Processor brand name | Intel Xeon |
| Last change | 63903513 |
| Product family | Intel Xeon Processor 5000 Sequence |
| Launch date | Q1’10 |
| Status | Discontinued |
| Born on date | Q1’10 |
| Product name | Intel Xeon X5650 (12M Cache, 2.66 GHz, 6.40 GT/s Intel QPI) |
| Maximum memory | 288 GB |
| Bus speed | 6.4 GT/s |
| Processor cache | 12288 KB |
| Supported memory types | DDR3-SDRAM |
| Product type | Processor |
| Packaging data | |
|---|---|
| Package type | Retail box |
| Weight & dimensions | |
|---|---|
| Processor package size | 42.5mm x 45mm |
| Package dimensions (WxDxH) | 42.5 x 42.5 x 45 mm |
| Other features | |
|---|---|
| On-board memory controller | Yes |
| Maximum internal memory | 288 GB |
| Cache memory | 12 MB |
| Intel® Virtualization Technology (Intel® VT) | VT-d, VT-x |
