Fractal Design Terra Small Form Factor (SFF) Graphite
- Install your choice of powerful GPU up to 322 mm in length, in a space-saving 10.4 L case
- Add natural materials to your setup with a front-facing panel cut from FSC-certified solid walnut
- Enjoy a sleek anodized aluminum exterior including an 8 mm-thick aluminum front
Terra is a PC case designed and engineered to reshape the small form factor gaming experience. Inspired by the homes of modern gamers, Terra incorporates boutique design features such as thick panels cut from anodized aluminum, CNC-milled details and FSC-certified solid walnut. Inside, it includes a PCIe 4.0 riser cable and features a stepless slidable central wall for build flexibility, providing space for a powerful GPU up to 322 mm in length.
Crafted to elevate
Designed and engineered to enhance small form factor gaming
Elegantly crafted
– Add natural materials to your setup with a front-facing panel cut from FSC-certified solid walnut
– Enjoy a sleek anodized aluminum exterior including an 8 mm-thick aluminum front
– Make the most of natural airflow through the ventilated top, side and bottom panels
Engineered for SFF gaming
– Experience powerful, uncluttered gaming, with the ability to install a GPU up to 322 mm long in a space-saving 10.4 L case
– Get a head start on your build with the included PCIe 4.0 riser cable
– Store up to two SSDs in the dedicated 2.5” drive mounts
Easily accessible
Slide open the top with an integrated tab and lift open the fully removable side panels for easy access to your components
Choose your accent
The Terra is available in your choice of three distinct anodized aluminum versions to perfectly complement and elevate your gaming space
Adjustable motherboard plate
Find your build’s ideal balance with 30 mm of internal flexibility provided by a stepless, movable central wall
Slide to strike the best ratio for your build, adapting the space for CPU cooling on one side and graphics card width on the other
Front-facing I/O
The solid walnut front panel features an aluminum power button and two USB ports for connecting devices, including one USB Type-C 20Gbps
Natural material
Enjoy a naturally unique finish, with an individual front panel cut from solid walnut.
Highly transportable
Features the ability to lock the top and side panels for safer transportation of your build
| Design | |
|---|---|
| Maximum PSU length | 13 cm |
| Maximum graphics card length | 32.2 cm |
| Maximum CPU cooler height | 7.7 cm |
| On/off button | Yes |
| Anti-dust filter | No |
| Illumination | No |
| Side window | No |
| Number of expansion slots | 3 |
| Number of 2.5″ bays | 2 |
| Supported motherboard form factors | Mini-ITX |
| Product colour | Graphite |
| Material | Aluminium, Walnut |
| Type | PC |
| Form factor | Small Form Factor (SFF) |
| Power supply | |
|---|---|
| Supported power supply form factors | SFX, SFX-L |
| Power supply included | No |
| Ports & interfaces | |
|---|---|
| USB Type-C ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| Cooling | |
|---|---|
| Top radiator installed | No |
| Rear radiator installed | No |
| Side radiator sizes supported | 120 mm |
| Front radiator installed | No |
| Bottom fans diameters supported | 120 mm |
| Number of bottom fans supported (max) | 1 |
| Storage | |
|---|---|
| SSD form factor | 2.5″ |
| Supported HDD sizes | 2.5″ |
| General | |
|---|---|
| Product family | Terra |
| Packaging content | |
|---|---|
| Manual | Yes |
| Weight & dimensions | |
|---|---|
| Weight | 3.1 kg |
| Height | 218 mm |
| Depth | 343 mm |
| Width | 153 mm |
| Packaging data | |
|---|---|
| Package weight | 4 kg |
| Package height | 292 mm |
| Package depth | 394 mm |
| Package width | 215 mm |
| Other features | |
|---|---|
| Volume | 10.4 L |
