Axis 02897-001 security camera Dome IP security camera Outdoor 2592 x 1944 pixels Ceiling/wall
- 4*5 MP at 20 fps per channel
- Remote pan, tilt, roll, zoom (PTRZ)
- Support for powerful analytics
- 360° IR illumination with individually controlled LEDs
- Built-in cybersecurity with Axis Edge Vault
AXIS P3747-PLVE lets you monitor four different areas, around the clock, and even in challenging lighting. Stylish and discreet, this camera also offers PTRZ functionality for ease of installation and configuration.
Wide area surveillance with high-quality overview—24/7
Ideal for expansive outdoor areas, AXIS P3747-PLVE offers four channels with 5 MP per channel at 20 fps to capture clear images over great distances. It includes day/night functionality and 360° IR illumination with individually controllable LEDs and a removable IR cut filter. So, you’ll enjoy clear images in low light or darkness as well as undistorted colors during the day. Forensic WDR ensures clarity when there’s both dark and light areas in the scene. Additionally, thanks to extended tilt functionality, all four sensors are fully tiltable ensuring you have the flexibility to see what you want to see. Furthermore, you can run AXIS Object Analytics on multiple channels to detect, classify, track, and count people and vehicles.
Brilliant design for cost-effective installation
This stylish, discreet camera can be mounted on ceilings for complete 360° coverage. Or corner mounted for 270° coverage. And with four camera heads in one camera, it offers fast, accurate, and cost-effective installation. Additionally, PTRZ (Pan, Tilt, Roll, Zoom) functionality means that there’s no need to physically adjust the camera. You can remotely move and set up your camera allowing for quick and easy installation. This ensures less disruption and downtime and reduces the need to dispatch a technician. Presets make it easy to configure multiple devices. In addition, Axis Zipstream significantly lowers bandwidth and storage requirements without compromising image quality.
Powerful with strong security
This AI-powered camera includes a deep learning processing unit (DLPU) so you can run powerful analytics on the edge. For instance, it comes with AXIS Object Analytics preinstalled to detect, classify, track, and count humans and vehicles. This DLPU also ensures improved processing and storage capabilities so you can collect and analyze even more data than before. Plus, it delivers valuable metadata facilitating fast, easy, and effi-cient forensic search capabilities in live or recorded video. Furthermore, Axis Edge Vault, a hardware-based cybersecurity platform, safeguards the device and protects sensitive information from unauthorized access. And it offers FIPS 140-2 Level 2 certified secure cryptographic key storage and operations.
| Performance | |
|---|---|
| Languages support | Arabic, Simplified Chinese, Traditional Chinese, Czech, Dutch, English, Finnish, French, Greek, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese |
| Number of languages | 19 |
| Built-in light | Yes |
| Remote viewing | Yes |
| Infrared (IR) cut-off filter | Yes |
| Day/night mode | Yes |
| Wide Dynamic Range (WDR) | Yes |
| Maximum operating distance | 20 m |
| Preset points | Yes |
| PTZ control | Yes |
| Connectivity technology | Wired |
| Placement supported | Outdoor |
| Type | IP security camera |
| Design | |
|---|---|
| IK code | IK10 |
| International Protection (IP) code | IP66 |
| Housing material | Aluminium, Polycarbonate (PC) |
| LED indicators | Activity |
| Product colour | Black, White |
| Mounting type | Ceiling/wall |
| Form factor | Dome |
| Camera | |
|---|---|
| Camera shutter speed | 1/19500 – 1 s |
| Camera pixel size | 2 µm |
| Lens viewing angle, vertical | 71.5 – 30.0° |
| Lens viewing angle, horizontal | 360° |
| Horizontal field of view (thermal module) | 360° |
| Minimum illumination | 0.1 lx |
| Camera tilt control | Yes |
| Panoramic camera | |
|---|---|
| Signal-to-Noise Ratio (SNR) (panoramic camera) | 55 dB |
| Sensor type (panoramic camera) | CMOS |
| Image sensor | |
|---|---|
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 2.78 mm (1 / 2.78″) |
| Number of sensors | 1 |
| Sensor type | CMOS |
| Lens system | |
|---|---|
| Focus | Motorized |
| Fixed focus | Yes |
| Focal length range | 3.18 – 7.42 mm |
| Zoom capability | Yes |
| Number of lenses | 3 |
| Night vision | |
|---|---|
| Infra-red wavelength | 850 nm |
| Number of illumination LEDs | 2 |
| LED type | IR |
| Night vision distance | 20 m |
| Night vision | Yes |
| Video | |
|---|---|
| Text caption overlay | Yes |
| Image quality adjustment | Brightness, Contrast, Mirror, Saturation, Sharpness |
| Privacy masking | Yes |
| Image stabilizer | Yes |
| Bit rate control | Variable Bit Rate (VBR) |
| Noise reduction technology | 2D noise reduction, 3D noise reduction |
| Video streaming | Yes |
| Video intelligence analytic | Yes |
| Frame rate | 20 fps |
| Video recording | Yes |
| Supported graphics resolutions | 640 x 360, 640 x 480 (VGA), 2560 x 1440, 2592 x 1944 |
| Video compression formats | M-JPEG, MPEG, MPEG4 |
| Video formats supported | H.264, H.265 |
| Total megapixels | 5 MP |
| Maximum resolution | 2592 x 1944 pixels |
| Audio | |
|---|---|
| Audio detection | Yes |
| Frequency range | 50 – 60 Hz |
| Audio formats supported | RTSP |
| Audio output channels | 2 channels |
| Audio input channels | 2 channels |
| Audio system full duplex | Yes |
| Audio system | 2-way |
| Built-in speaker(s) | Yes |
| Network | |
|---|---|
| Quality of Service (QoS) support | Yes |
| Streaming method | Multicast |
| Number of simultaneous live view channels | 4 channels |
| Supported network protocols | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSa , HTTP/2, TLSb , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf) |
| Networking standards | IEEE 802.1AE, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Storage | |
|---|---|
| RAM capacity | 4096 MB |
| Flash memory | 8192 MB |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Ports & interfaces | |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Security | |
|---|---|
| Human and vehicle targets classification | Yes |
| Video motion detection | Yes |
| Motion sensor | Yes |
| Active tampering alarm | Yes |
| IP address filtering | Yes |
| HTTPS encryption | Yes |
| Intelligent Video Surveillance (IVS) system features | Human detection, Vehicle detection |
| Digest authentication | Yes |
| Security algorithms | 256-bit AES-XTS, FIPS 140-2, HTTPS, SNMP |
| Privacy protection | Yes |
| Alert notification type | |
| Network access storage (NAS) | Yes |
| Pixel counter | Yes |
| Password protection | Yes |
| Management features | |
|---|---|
| Remotely operated | Yes |
| Power | |
|---|---|
| Power consumption (max) | 23.7 W |
| Power consumption (typical) | 10.8 W |
| Power source type | PoE |
| Operational conditions | |
|---|---|
| Storage relative humidity (H-H) | 5 – 95% |
| Operating relative humidity (H-H) | 10 – 100% |
| Storage temperature (T-T) | -40 – 65 °C |
| Operating temperature (T-T) | -40 – 50 °C |
| Weight & dimensions | |
|---|---|
| Weight | 3 kg |
| Height | 75 mm |
| Depth | 220 mm |
| Width | 141 mm |
| Features | |
|---|---|
| License plate recognition | Yes |
| Sustainability | |
|---|---|
| Compliance certificates | BSMI, CE, Federal Communications Commission (FCC), ICES, KC, RCM, REACH, RoHS, Trade Agreements Act (TAA), UL, VCCI, cUL |
| Packaging content | |
|---|---|
| Manual | Yes |
| Memory card included | Yes |
| Mounting brackets included | Yes |
| Mounting kit | Yes |
| Number of cameras | 1 |
| Other features | |
|---|---|
| Doesn’t contain | BFR, CFR, PVC |
| Warranty period | 5 year(s) |
